PB01-GML
PRODUCT DESCRIPTION
Our products are subjected to a rigorous testing process to ensure that they meet the highest standards with a defect rate of less than 1%.
Product Specs
|
PB01 |
PB01-GML(POE optional) |
|
CPU |
N4000，N4100，J4105，N4120，J4125 |
|
DRAM |
Dual DDR4 260pin SODIMM SLOT;MAX:16GB |
|
Storage |
64GB/128GB Emmc;M.2 slot:NVME SSD or SATA SSD;2.5’SATA HDD |
|
WIFI |
AC3165/AC7265,support dual band 2.4G&5G AC wifi,BT4.0 |
|
Ethernet |
10M/100M/1000Mbps;DUAL LAN,One lan support POE＋（Power Over Ethernet)(PD) |
|
Audio codec |
3.5mm earphone mic |
|
Type-C |
Only USB3.1 GEN1 |
|
HDMI |
HDMI REDRIVER&RETIME; Support HDMI2.0,Up to 4K@60 |
|
DP |
CPU Integrated, DP1.2 up to 4K@60 DP connector |
|
VGA |
SUPPORT |
|
TF or SD |
SUPPORT |
|
USB3.0 |
USB3.1 GEN1×4 |
|
USB2.0 |
N/A |
|
PCB |
148×105×1.2mm |
Product Certifications
